target-elasticsearch

target-elasticsearch is a Singer target for Elastic.

Some target development because I am currently hacking together something together with a bash script Built with the Meltano Tap SDK for Singer Taps.

Video

Settings

Setting	Required	Default	Description
scheme	True	http	http scheme used for connecting to elasticsearch
host	True	localhost	host used to connect to elasticsearch
port	True	9200	port use to connect to elasticsearch
username	False	None	basic auth username as per elastic documentation
password	False	None	basic auth password as per elastic documentation
bearer_token	False	None	Bearer token for bearer authorization as per elastic documentation
api_key_id	False	None	api key id for auth key authorization as per elastic documentation
api_key	False	None	api key for auth key authorization as per elastic documentation
ssl_ca_file	False	None	location of the the SSL certificate for cert verification ie. /some/path as per elastic documentation
index_format	False	ecs-{{ stream_name }}-{{ current_timestamp_daily }}	can be used to handle custom index formatting such as specifying -latest index. Default options: Daily {{ current_timestamp_daily }}, Monthly {{ current_timestamp_monthly }}, or Yearly {{ current_timestamp_yearly }}. You should use fields specified in index_schema_fields such as {{ _id }} or {{ timestamp }} . There are also helper fuctions such as {{ to_daily(timestamp) }}`.
index_schema_fields	False	None	this id map allows you to specify specific record values via jsonpath from the stream to be used in index formulation.
metadata_fields	false	None	this should be used to pull out specific fields via jsonpath to be used on for ecs metadata patters
index_mappings	false	None	Define field mappings for each stream/index. Creates or updates Elasticsearch index mappings with specified field types and properties. Format: {"stream_name": {"properties": {"field_name": {"type": "text"}}}}. See MAPPING_EXAMPLES.md for detailed examples.
request_timeout	false	10	increase timeout to send big butches of data Elasticsearch connection arguments
retry_on_timeout	false	True	increase timeout to send big butches of data Elasticsearch connection arguments

A full list of supported settings and capabilities is available by running: target-elasticsearch --about

Installation

git clone [email protected]:dtmirizzi/target_elasticsearch.git
cd target_elasticsearch
pipx install .

Configuration

Accepted Config Options

A full list of supported settings and capabilities for this tap is available by running:

target_elasticsearch --about

Index Mappings (NEW)

The index_mappings configuration allows you to define field mappings for each stream/index, enabling:

• Better Performance: Proper field types improve query performance
• Storage Optimization: Appropriate field types reduce storage requirements
• Enhanced Search: Text analysis and keyword fields enable better search capabilities
• Data Integrity: Field types enforce data consistency

Example Configuration

config:
  # ... other settings ...
  index_mappings:
    users:
      properties:
        email:
          type: keyword
        created_at:
          type: date
        full_name:
          type: text
          analyzer: standard
    orders:
      properties:
        order_id:
          type: keyword
        total_amount:
          type: scaled_float
          scaling_factor: 100

For detailed examples and advanced usage, see MAPPING_EXAMPLES.md.

Target Authentication and Authorization

You can easily run target-elasticsearch by itself or in a pipeline using Meltano.

There are 4 types of auth supported by this target:

• Basic Auth
• Access Token
• Bearer Token
• SSL Based

Executing the Tap Directly

target_elasticsearch --version
target_elasticsearch --help
target_elasticsearch --config CONFIG --discover > ./catalog.json

Developer Resources

Initialize your Development Environment

pipx install poetry
poetry install
poetry run pre-commit install

Create and Run Tests

1. Create tests within the target_elasticsearch/tests subfolder
2. To Run tests, first set environment variables in your current shell for all required settings from the Settings section above. Example for UNIX base systems running export Target_elasticsearch_USER_ID="xxxxx" then run:

poetry run pytest

You can also test the target-elasticsearch CLI interface directly using poetry run:

poetry run target_elasticsearch --help

Testing with Meltano

Note: This tap will work in any Singer environment and does not require Meltano. Examples here are for convenience and to streamline end-to-end orchestration scenarios.

Your project comes with a custom meltano.yml project file already created.

Next, install Meltano (if you haven't already) and any needed plugins:

# Install meltano
pipx install meltano
# Initialize meltano within this directory
cd target-elasticsearch
meltano install

# You can spin up elastic locally
make local-es

Now you can test and orchestrate using Meltano:

meltano install
# Test invocation:
meltano invoke target-elasticsearch --version
# test configuration
meltano config target-elasticsearch set --interactive
# OR run a test `elt` pipeline:
meltano elt tap-smoke-test target-elasticsearch

SDK Dev Guide

See the dev guide for more instructions on how to use the SDK to develop your own taps and targets.
