A comprehensive and flexible library for controlling 16x2 alphanumeric LCD displays with HD44780-compatible controllers using STM32 microcontrollers and HAL (Hardware Abstraction Layer). This library supports both 4-bit and 8-bit parallel communication modes.
Alphanumeric LCD displays are character-based modules that can display text and custom characters. The most common configuration is 16x2 (16 characters per row, 2 rows), which this library is optimized for.
The HD44780 LCD controller supports two parallel communication modes:
- Uses all 8 data lines (DB0-DB7)
- Faster data transmission (complete byte sent in one cycle)
- Requires more GPIO pins (10 pins total: RS, EN, DB0-DB7)
- Ideal for performance-critical applications with abundant GPIO
- Uses only 4 data lines (DB4-DB7)
- Slower data transmission (byte sent in two cycles: high nibble, then low nibble)
- Requires fewer GPIO pins (6 pins total: RS, EN, DB4-DB7)
- Ideal for GPIO-limited projects while maintaining full functionality
|
Tip If you're looking to better understand how to navigate and use my GitHub repositories — including exploring their structure, downloading or cloning projects, submitting issues, and asking questions, |
|
|
|
Important Begin your embedded systems journey with clarity and purpose. This episode outlines a structured roadmap for mastering microcontrollers, communication protocols, hardware design, and project development. |
|
|
|
Caution It is absolutely critical that you carefully read every single word of this document, line by line, to ensure you don't miss any details. Nothing can be overlooked. |
||
✅ Dual Mode Support
- Complete 4-bit mode implementation
- Complete 8-bit mode implementation
- Easy switching between modes (separate source files)
✅ Display Control
- Initialize and configure LCD
- Clear display and control cursor position
- Display text strings and individual characters
- Control display, cursor, and blink states
✅ Custom Characters
- Create up to 8 custom 5×8 pixel characters
- Store in CGRAM for repeated use
- Perfect for icons, symbols, and special graphics
✅ Backlight Control
- Optional backlight ON/OFF control
- Transistor-driven for proper current handling
✅ Flexible Pin Mapping
- Easy pin configuration via header file
- Connect LCD to any available GPIO pins
- No hardcoded pin assignments
- Compatible with any STM32 GPIO port
✅ Robust Implementation
- Proper HD44780 initialization sequence
- HAL-based delay functions for accurate timing
- Position tracking and auto-wrapping
- Comprehensive error prevention
✅ STM32 HAL Integration
- Built on STM32 HAL library
- Compatible with STM32CubeMX generated code
- Works with all STM32 families (F0, F1, F3, F4, F7, H7, L0, L1, L4, etc.)
- Easy integration with existing STM32 HAL projects
Here you'll find a collection of useful links and videos related to the topic of STM32 microcontrollers.
Tip
The resources are detailed in the sections below.
To access any of them, simply click on the corresponding blue link.
-
The aLCD Library provides a comprehensive driver for HD44780-compatible 16x2 LCDs on STM32 microcontrollers. It supports both 4-bit and 8-bit communication modes with flexible pin mapping via STM32CubeMX. The API includes functions for initialization, controlling the display, cursor, and backlight, and writing characters and strings to specific positions. Additionally, it allows for the creation and use of up to 8 custom characters.
-
This repository offers a comprehensive guide to STM32 microcontroller programming, focusing on the STM32F103C8T6. Explore STM32 architecture, peripheral configuration, timers, interrupts, communication protocols (UART, SPI, I2C), and real-time applications through practical examples and hands-on projects. Whether you're a beginner or an experienced developer, this resource will help you build a strong foundation and advance your skills in STM32 embedded development.
STM32, Alphanumeric LCD
└─ [aKaReZa 130 - HAL, aLCD]
├─ Project — Creating a new STM32 project.
├─ GPIO — Pin configuration for LCD connection.
├─ Header — Rewriting aKaReZa.h for STM32.
├─ Refactor — Adapting LCD functions to HAL.
├─ API — Core LCD functions overview.
├─ Performance — Techniques to boost display speed.
└─ Repository — STM32-compatible alcd library usage.
|
Bridge AVR and STM32 environments by adapting the aLCD library for STM32 using the HAL framework. This tutorial guides you through creating a new STM32 project, configuring GPIO pins, and rewriting the shared header file aKaReZa.h. You’ll also learn to refactor LCD functions for HAL, understand the core LCD API, and apply performance optimization techniques. Finally, the episode introduces the STM32-compatible alcd repository—a practical resource for reusing and enhancing LCD code across platforms. |
|
