StartSCH

The news site of the Schönherz Dormitory and the Budapest University of Technology and Economics. Built with ASP.NET, Blazor, Entity Framework, and Lit.

Running locally

Instructions on how to quickly set up a development environment.

Dependencies

• .NET 10 SDK
  • make sure you can run dotnet --info and it shows 10.x.x under .NET SDKs installed
• bun
  • make sure you can run bun

AuthSCH credentials

https://auth.sch.bme.hu > Bejelentkezés > Fejlesztői konzol > Új hozzáadása, set Átirányítási cím to http://localhost:5264/signin-oidc, then use the created credentials in the following commands:

Running from the terminal

git clone https://github.com/kir-dev/StartSCH
cd StartSCH/StartSch
dotnet user-secrets set AuthSch:ClientId YOUR_AUTHSCH_CLIENTID
dotnet user-secrets set AuthSch:ClientSecret YOUR_AUTHSCH_CLIENTSECRET
dotnet run

Debugging

I recommend using JetBrains' .NET IDE, Rider for working on StartSCH. Below you can find instructions on how run StartSCH in debug mode using it:

1. Install Rider
2. Open StartSCH.slnx
3. Ensure AuthSCH credentials are correctly set up: Explorer > StartSch > right-click > Tools > .NET User Secrets
4. Click Debug 'StartSch' (the green bug icon in the top right) or press F5

Running with hot reloading

Hot reloading allows updating the code of the app while it is running without restarting it. Rider's built-in hot reloading is not that great, so I highly recommend just running StartSCH from the terminal if you don't need a debugger:

Terminal 1

cd StartSCH/StartSch

# Run StartSCH with hot reloading:
dotnet watch

Terminal 2

cd StartSCH/StartSch

# Use Bun to automatically bundle TypeScript and CSS files when they change
# (this is handled by dotnet build when not using hot reloading)
bun watch

Development

Overview

If you don't like reading, check out these files and directories for a quick overview of the project:

• StartSch/
  • Program.cs: the entrypoint of the server
  • StartSch.csproj: NuGet dependencies
  • package.json: NPM dependencies and CSS/TS build scripts
• StartSch.Wasm/: C# code and Blazor components that can run in the user's browser. Currently unused.
• .config/kubernetes.yaml: Kubernetes resource definitions required to run the production version of StartSCH in Kir-Dev's vCluster in the KSZK's Kubernetes cluster.

The server

We use ASP.NET, which is a free, open-source, cross-platform, and high-performance HTTP server built on .NET, that supports a boatload of different use cases.

I recommend reading the following sections of its documentation to get a feel for it:

• Overview of ASP.NET Core
• ASP.NET Core fundamentals overview
• ASP.NET Core Blazor
• APIs overview

Configuration

• ASP.NET docs: Configuration: environment variables, appsettings.*.json, dotnet user-secrets, etc.
• ASP.NET docs: Options pattern: accessing the above using type-safe C# classes

Setting up push notifications

• MDN: Web Push API
• web.dev: Push notifications overview

To send push notifications, most push services, for example, Apple, require a VAPID key pair.

If you want to try out push notifications, you can use a VAPID key generator to generate these, then configure StartSCH to use them:

cd StartSCH/StartSch

dotnet user-secrets set Push:PublicKey "..."
dotnet user-secrets set Push:PrivateKey "..."
# Push service providers use this if there are issues with a sender, probably not important when developing
dotnet user-secrets set Push:Subject "mailto:[email protected]"

Database

The production version of StartSCH uses PostgreSQL to persist data, but to simplify setting up a dev environment, SQLite is also supported, as it does not require any configuration.

We use Entity Framework to access the database from C# code. For most changes, you can get by with only a basic knowledge of Entity Framework, but if you have the time, I highly recommend also reading the documentation for Postgres and SQLite (the Postgres one is especially good).

If you are new to Entity Framework, I recommend skimming through the Entity Framework introduction, then the Overview pages for the sections in the table of contents on the left.

Migrations

• EF docs: Migrations Overview
• EF docs: Migrations with Multiple Providers

If needed, use the below commands to work with EF migrations:

cd StartSCH/StartSch

# Make sure you can run `dotnet ef`.
# One of these commands, ideally the first one, should install it.
dotnet tool restore
dotnet tool install dotnet-ef
dotnet tool install dotnet-ef --global

# Describe the migration
export MIGRATION_MESSAGE=AddSomethingToSomeOtherThing

# Add migration
dotnet ef migrations add --context SqliteDb $MIGRATION_MESSAGE
dotnet ef migrations add --context PostgresDb $MIGRATION_MESSAGE

# Remove latest migration
dotnet ef migrations remove --context SqliteDb
dotnet ef migrations remove --context PostgresDb

# Reset migrations
rm -r Data/Migrations/Postgres Data/Migrations/Sqlite
dotnet ef migrations add --context SqliteDb --output-dir Data/Migrations/Sqlite $MIGRATION_MESSAGE
dotnet ef migrations add --context PostgresDb --output-dir Data/Migrations/Postgres $MIGRATION_MESSAGE

New migrations are applied automatically by StartSCH before it starts serving requests.

Injecting a Db instance

• EF docs: DbContext Lifetime, Configuration, and Initialization
• EF docs: ASP.NET Core Blazor with Entity Framework Core

Depending on where you want to access the database, you have to decide between injecting Db or IDbContextFactory<Db>.

For example, static forms or API controllers that run in a scope should use Db, while methods in an interactive Blazor component should request a new Db instance every time they run.

Tips

Reading TLS encrypted HTTP requests using Wireshark

• Wireshark/TLS
• dotnet/runtime: Support SSLKEYLOGFILE in SslStream

Might be useful when trying to reverse-engineer some APIs or debugging issues while developing StartSCH.

1. Run StartSCH using the SSLKEYLOGFILE environment variable set to a path to a non-existent file (e.g. /home/USER/keylog.txt)
   • This is easiest using StartSch/Properties/launchSettings.json: add "SSLKEYLOGFILE": "/home/USER/keylog.txt" to the environmentVariables section under the launch profile you are using (http by default)
2. Add a AppContext.SetSwitch("System.Net.EnableSslKeyLogging", true); line to the top of Program.cs
3. Set Wireshark/Edit/Preferences/Protocols/TLS/(Pre)-Master-Secret log filename to the path in the above environment variable
4. Run StartSCH

SSLKEYLOGFILE also works in Firefox and Chrome:

SSLKEYLOGFILE=~/keylog.txt firefox

Make sure the browser is not already running (in the background), otherwise it won't pick up the env var.

Contributing

1. (Optional) Create or choose an issue to work on and assign it to yourself
2. Create and checkout a new Git branch named feature/... based on origin/main
   • git checkout -b feature/something
3. Write code
   • Running StartSCH locally and setting up an IDE
   • Development documentation
4. Commit
   • git add .
   • git commit -m "Add ..."
     • Follow How to Write a Git Commit Message
5. Push your changes to GitHub
   • git push
6. Open a pull request. If you want to keep working on it, mark it as a draft.
7. Repeat 3-5. until satisfied
8. Request a review on your pull request

We use squash merging for pull requests (commits from a PR get squashed into a single commit on the main branch). Try to keep pull requests focused on a single feature.
