MAAD (Multi-Agent Autonomous Developer) v2.0

MAAD is an advanced AI orchestration system featuring 5 specialized agents (Planner, Architect, Developer, Debugger, Tester) working in a transparent pipeline. With per-agent model optimization, you can configure different LLMs for each agent to maximize quality while controlling costs.

Transform plain-English product ideas into production-ready full-stack applications.

🏗 System Architecture

                     ┌──────────────────────┐
                     │    USER PROMPT       │
                     │  "Build a todo app"  │
                     └──────────┬───────────┘
                                │
                     [ Next.js Frontend ]
                                │
         ┌──────────────────────▼──────────────────────┐
         │          FASTAPI ORCHESTRATOR               │
         │      (Sequential Agent API Calls)           │
         └──────────────────────┬──────────────────────┘
                                │
    ┌────────────┬──────────────┼──────────────┬───────────────┐
    │            │              │              │               │
    ▼            ▼              ▼              ▼               ▼
  ┌───────┐   ┌──────────┐  ┌────────────┐  ┌────────┐   ┌────────┐
  │Planner│   │Architect │  │ Developer  │  │Debugger│   │ Tester │
  │       │   │          │  │            │  │        │   │        │
  │Gemma4 │   │Llama-70B │  │ Gemma-4    │  │Llama-8B│   │Gemma-4 │
  └───────┘   └──────────┘  └────────────┘  └────────┘   └────────┘
                                │
         ┌──────────────────────▼──────────────────────┐
         │      FASTAPI BACKEND + SESSION DB           │
         │  (SQLite state persistence, model routing)  │
         └───────────────────────────────────────────────┘

✨ Key Features (v2.0)

🎯 Per-Agent Model Configuration

Each agent uses an optimized model for its specific task:

Agent	Model	Task	Quality	Speed
Planner	Gemma-4	Create dev plan	⭐⭐⭐⭐	⚡⚡⚡⚡⚡
Architect	Llama-3-70B	Design system	⭐⭐⭐⭐⭐	⚡⚡
Developer	Gemma-4	Write code	⭐⭐⭐⭐⭐	⚡⚡⚡⚡
Debugger	Llama-3-8B	Review & fix	⭐⭐⭐⭐	⚡⚡⚡⚡⚡
Tester	Gemma-4	Generate tests	⭐⭐⭐⭐	⚡⚡⚡⚡

🔄 Pipeline Orchestration

• Sequential Agent Flow - Planner → Architect → Developer → Debugger → Tester
• Error Handling & Retries - Built-in resilience for each agent
• Easy Extensibility - Add agents or modify flow without code changes
• Session Tracking - Persist and inspect each stage output in the backend

💾 Session-Based State Management

• Persistent Storage - All agent outputs saved in SQLite
• Resumable Pipelines - Query any session to retrieve outputs
• Scalable - Drop-in PostgreSQL support for production

🚀 Model Flexibility

• Free Tier Ready - All default models available on OpenRouter free tier
• Custom Models - Switch to Claude, GPT-4, or any OpenRouter model
• Cost Optimization - Mix free and paid models strategically

🚀 Quickstart

1️⃣ Prerequisites

• Docker & Docker Compose
• OpenRouter API key (free tier: https://openrouter.ai)

2️⃣ Clone & Configure

git clone https://github.com/maad-dev/maad.git
cd maad
cp .env.example .env

Update .env with your OpenRouter API key:

OPENROUTER_API_KEY=sk-or-xxxxxxxxxxxxx

3️⃣ Start All Services

docker-compose up -d

Services will be available at:

• 🖥️ Frontend: http://localhost:3000
• 🔧 FastAPI Backend: http://localhost:8000

4️⃣ Test the Pipeline

# Using cURL
curl -X POST http://localhost:8000/pipeline/init \
  -H "Content-Type: application/json" \
  -d '{
    "task": "Build a todo app with Next.js",
    "scope": "minimal"
  }'

# Or use the frontend at http://localhost:3000

📖 Documentation

• Backend Details - Python code structure

⚙️ Configuration

Custom Models Per Agent

Edit .env to use different models:

# Free tier (default)
PLANNER_MODEL=google/gemma-4-26b-a4b-it:free
ARCHITECT_MODEL=meta-llama/llama-3-70b-instruct:free
DEVELOPER_MODEL=google/gemma-4-26b-a4b-it:free
DEBUGGER_MODEL=meta-llama/llama-3-8b-instruct:free
TESTER_MODEL=google/gemma-4-26b-a4b-it:free

# Premium models (update OpenRouter account)
# ARCHITECT_MODEL=anthropic/claude-3-opus
# DEVELOPER_MODEL=openai/gpt-4-turbo

Deployment Options

Docker Compose (Development)

docker-compose up

Production Scaling

# Use PostgreSQL instead of SQLite
# Deploy multiple FastAPI instances behind nginx/k8s
# Add Redis for caching

🏃 Manual Development Setup

Frontend (Next.js)

cd frontend && npm install && npm run dev

Backend (FastAPI)

cd backend
python -m venv venv
source venv/bin/activate
pip install -r requirements.txt
uvicorn main:app --reload

📊 Performance

Typical execution timeline:

• Planner: 10-15s
• Architect: 15-20s
• Developer: 30-45s
• Debugger: 10-15s
• Tester: 15-25s

Total: ~80-120 seconds (1.5-2 minutes) for complete pipeline

🛠 Tech Stack

• Frontend: Next.js 14, Tailwind CSS, TypeScript
• Backend: Python 3.11+, FastAPI, Pydantic, SQLite/PostgreSQL
• Orchestration: FastAPI service layer
• AI Models: OpenRouter API (Gemma-4, Llama-3, Claude, GPT-4, etc.)
• Deployment: Docker, Docker Compose

📝 API Overview

Initialize Pipeline

POST /pipeline/init
{
  "task": "Build a todo app",
  "scope": "minimal|standard|full"
}

Get Session Results

GET /session/{session_id}

Individual Agent Endpoints

POST /agent/planner
POST /agent/architect
POST /agent/developer
POST /agent/debugger
POST /agent/tester

🐛 Troubleshooting

Backend not responding?

docker-compose logs backend
curl http://localhost:8000/health

Model not found?

# Verify OpenRouter API key and account
curl -H "Authorization: Bearer $OPENROUTER_API_KEY" \
  https://openrouter.ai/api/v1/models | grep -i gemma

📈 Scaling Strategy

1. Single Instance - Perfect for development (10 concurrent requests)
2. Horizontal Scaling - Run multiple backends with load balancer + PostgreSQL
3. Advanced Workflows - Use parallel execution for multiple agents
4. Caching - Redis for planner output reuse
5. Monitoring - ELK stack or Datadog integration

🗓️ Roadmap

• Per-agent model configuration
• API-based orchestration
• Session-based state management
• Parallel agent execution
• Custom workflow templates
• Result webhooks to external systems
• Advanced model parameter tuning
• Multi-language code generation
• Kubernetes deployment

📄 License

MIT License - See LICENSE file

👥 Contributing

Contributions welcome! See CONTRIBUTING.md

---

Version: 2.0.0 (2026-04-18)
Status: 🟢 Production Ready
